Disclaimer: Color codes in the catalogue are for reference only
01
Overview
Production
Our filaments are developed in-house and are produced in ISO 9001 certified facilities using the best materials available. We have full control over the product specifications, production chain, and quality control such to ensure consistency and high standards that we ourselves and our clients demand.
Certification:
Infix 3D Printing Filaments comply with the following certification standards:
Supply
Strategic Supply:
Due to our vertical integration, we can offer very competitive prices along with stable and consistent supply on bulk orders or longer term contracts.
Volume:
Our production is in shipping container sized batches, but we can include smaller orders for more accessible MOQs.
Customization:
We produce and stock a standard range of PLA+ and PETG filaments and can also make to order other bespoke material configurations and spool sizes.
02
Reference Information
Filament:
Diameter:
Available as Standard: 1.75 mm
Available on Order: 2.85 mm or 3.00 mm
Tolerance: +/- 0.03 mm
Size (Net Weight):
Available as Standard: 1 kg
Available on Order: 0.5 kg, 2 kg, 3 kg, 5 kg
Unit Spool
As standard, Infix 3D printing filaments are supplied with 1kg cardboard spools.
Eco-Friendly:
Standard:
Fully Recyclable Cardboard Made from Recycled Cardboard
Optional:
Fully Recyclable Polypropylene Plastic
AMS Compatible:
Standard:
Reinforced edges on cardboard spool
Optional:
Optional AMS spool weight accessory
Injected PS spools available on order. For OEM orders, the spools available on order. For OEM orders, the spools available on order. For OEM orders, the spool design, colours and graphics can be customized.
Spool Size
Flange Diameter
Bore Diameter
Traverse Length
0.5
kg
200
mm
50
mm
38
mm
1
kg
198
mm
53
mm
55
mm
2
kg
230
mm
50
mm
77
mm
3
kg
200
mm
33
mm
160
mm
5
kg
250
mm
33
mm
160
mm
Unit Box
Unit Boxes made from 100% recyclable cardboard and contain:
vacuum sealed bag for the filament roll
desiccant inside the vacuum sealed bag
additional zip-lock bag for resealing after use
Unit Box Dimensions (laid flat):
Width
Depth
Height
210
kg
203
mm
65
mm
Multipack Box
We ship in multipack cardboard boxes of 10 standard 1 kg units.
Two rows of 5 boxes are placed in a vertical position along the long end of the Multipack box.
The multipack boxes (MB) are fully recyclable.
For OEM orders, the design on the MB can be customized.
Total Volume: 0.035 m^3 Gross weight: 13 kg
Multipack Box Dimensions (laid flat):
Length
Width
Height
435
kg
350
mm
225
mm
Pallet
Standard Shipping Pallet Configuration:
Euro-Pallet containing 45 Multipack Boxes with a total capacity of 450 standard 1 kg spools, with no overhang.
Pallet Configuration:
UB: Unit Box; MB: Multipack Box
Side 1
5 rows of 5 MB (resting on long narrow side) = 25 MB = 250 UB
Pallet Load Length: 5x MB height = 1,125 mm
Pallet Load Height: 5x MB width = 1,750 mm
Side 2
4 rows of 5 MB (resting on short narrow side) = 20 MB = 200 UB
Gross Pallet Height: 1,750 mm (net highest side) + 144 mm (empty pallet height) = 1,894 mm
Absolute Pallet Dimensions
Length
200
38
1,250
kg
1,000
mm
2,200
mm
Net Pallet Content:
45x MB = 585 kg
Pallet Gross Weight:
610 kg +/- 5kg
Recycling Information
We are environmentally conscious and have designed the product packaging and accessories to be recyclable. For regulatory aspects, refer to the product safety datasheets in the Material Types section.
The recycling guide presented is featured on each Unit Box
03
Material Types Overview
Infix PLA+ Filaments
PLA is a biodegradable, recyclable polymer made from fermented plant starch. It is widely regarded as the go-to filament type for the majority of 3D printing applications, as it is easy to print on almost any FDM or FFF 3D printers and has a high print quality with minimal warping.
Infix PLA+ has been carefully designed to increase strength and to lower the melting flow index (MFI) of normal PLA for better performance.
PLA is a biodegradable, recyclable polymer made from fermented plant starch. It is widely regarded as the go-to filament type for the majority of 3D printing applications, as it is easy to print on almost any FDM or FFF 3D printers and has a high print quality with minimal warping.
Infix PLA+ has been carefully designed to increase strength and to lower the melting flow index (MFI) of normal PLA for better performance.
The PLA+ Semi-Gloss range is the most versatile PLA+ 3D printing filaments we have on offer. Whether you are a hobbyist, a print farm operator or even an industrial manufacturer, the Semi-Gloss range will meet the majority of your demands.
Infix PLA+ Matte filaments are ideal for applications where accuracy and finish quality perception are needed. The matte finish helps to conceal the layer lines and highlights the fine details on a print. Functional parts also work great with this finish.
Infix PLA+ Silk range is a great choice for detailed decorative pieces. The formulation of the filament produces a satin effect that does a great job at concealing print lines.
Infix PLA+ Multicolour range is aimed for decorative applications with unique visual effects. Combinations of 2 to 5 colours with a satin effect are offered as well as an illuminated version for additional wow factor.
Infix PLA+ Fluorescent range is a great choice for path guide pieces or other applications where a glow in the dark effect is desired. The effect is achieved after exposing the filament to UV light, and it is temporary. Application examples: garden pathways, fire exit guides, childrens' nightlights, bar decorations, party pieces, etc.
Infix PLA+ Translucent filaments are great for applications where a certain level of transparency is needed. Illuminated products, such as lamps, lamp shades, or decorative objects such as vases or ornaments can benefit from this range of filaments.
Infix PETG filament is the usual material of choice for professional applications, due to its excellent mechanical properties and ease of print. It is a great choice for functional projects where mechanical strength, thermal and chemical durability are important. Recyclable and food-safe in its additive-free variant.
Infix TPU filaments have been developed for complex parts requiring a hardness shore of 85-90A with increased printing speeds of up to 5 times faster than regular TPU. The filament itself has a shore of 82D making it ideal in multi colour applications where an automated filament management system is used as it tends to not unwind of the spool like regular TPU would.
Infix High Speed PLA filament has been specifically designed to retain the features of the Infix PLA+ filament and to maximize printing speeds which can reach up to 500mm/s in the right conditions. It is most suitable for projects where manufacturing efficiency and detailed printing are required.
Infix High Speed PETG filament is a great choice for maximizing production without compromising on the mechanical properties and thermal and chemical advantages of Infix PETG filaments.
Additional printer configurations can be provided on request.
Disclaimer:
The configuration files from this website, containing filament and slicer profiles, are provided for reference and without liability. For optimal printing results testing and fine-tuning of the values appropriate for the specific application and respective technical environment is necessary. On request, Infix can assist with the fine-tuning process as part of additionally provided support services, which may include specific guarantees. For more information, please contact us.
